Wrangling Ruby and ImageMagick in Cygwin

Wrangling Ruby and ImageMagick in Cygwin

Cygwin can be a clever way for Windows environments to leverage the power of tools that might otherwise only be available in the Unix realm. If you attempt Ruby and ImageMagick stuff in it, though, be prepared for a fight…

Cygwin-ImageMagick-Ruby Cube


Rejected titles for this article include: (a) “It’s not whether you Cygwin or Cyglose: Just quit now!”; (b) “Build a Ruby Goldberg Machine in 146 Easy Steps”; and (c) “Cygwin and Ruby: Forking Hell!”

Cygwin Logo

I won’t explain much of Cygwin other than to say it’s a way to run Unix software natively on Windows. More-precisely, it’s a platform that allows for Unix software to be compiled to target Windows. This is done with shared Cygwin DLLs which seek to provide POSIX-compliant system calls, path mapping, and so-on through a Unix compatibility layer.

While Cygwin is a clever piece of work and a means to an end, I’ve concluded that it is not a suitable way to build a complete development environment, especially where Ruby is involved. You will probably be better off if you switch entirely to (say) Linux, or stick with Windows, optionally with Cygwin playing a minor role in your toolchain.

Having said that, I will share my experiences with getting Ruby, RVM, ImageMagick, and ultimately my entire nanoc site build process to work under Cygwin.

The Problem

If you don’t care about the background of the issues, and just want to trace my steps that arrive at a usable environment, just see My Solution and The Steps below.

One great thing about Unix software is the intent that the source code be portable between different Unix flavours. Libraries and conventions are used, as defined by the POSIX standards, such that there are accepted ways that common tasks are usually done. Most free and open Unix software is initially distributed as source code, able to be compiled specifically for the target system. In principle, any Operating System that is at least mostly POSIX-compliant should be able to compile and run this software without issues.

Unfortunately, Windows is not particularly POSIX-compliant, and while Cygwin makes a noble attempt to bridge the gap, there are some things which either haven’t been adequately realised in Cygwin, or will never be possible due to key differences in Windows’ core design.

ImageMagick reflected in a fork

One issue which comes up regularly is fork() problems, related to multi-threading. While Unix software relies heavily on the fork-exec model, Windows uses a completely different approach which is not compatible. Cygwin attempts to work around this by ensuring libraries (e.g. DLLs) will be loaded into fixed, known address spaces between processes, and this requires “rebasing” of the libraries to prevent collisions (and hence prevent them from relocating).

In dealing with this issue, the rebaseall command comes up a lot, and there are discussions on the topic and why the issue manifests, but it can’t always be solved because:

  • The rebaseall command doesn’t always know how to automatically find all libraries/modules that may need treatment in order to be loaded properly;
  • Sometimes there simply isn’t enough address space for all libraries; and
  • Adding a new Cygwin package may require that you rebase all over again.

My Specific Problem with Ruby and ImageMagick

I’ve found that the fork() problem has the potential to be significantly harder to deal with when you’re using Ruby, as each gem may require its own library to be loaded by the Ruby environment, and it is hard to get the rebaseall command to consider these.

ImageMagick logo

When I started using the RMagick gem, I hit a wall and I couldn’t proceed. RMagick provides Ruby bindings for the ImageMagick image processing libraries. I had intended to use it to process the images of my blog, producing inline-sized versions and thumbnails from full-sized originals, while also handling things like web optimisation. Instead, though, I was met with errors along the lines of the following, at the instant that Ruby tries to load the RMagick gem via require 'rmagick':

4 [main] ruby 3004 child_info_fork::abort: C:\cygwin\bin\cygpixman-1-0.dll: Loaded to different address: parent(0x5DF00000) != child(0x2B80000)
2 [main] ruby 284 child_info_fork::abort: C:\cygwin\bin\cygpixman-1-0.dll: Loaded to different address: parent(0x5DF00000) != child(0x5B0000)
1 [main] ruby 4548 child_info_fork::abort: C:\cygwin\bin\cygpixman-1-0.dll: Loaded to different address: parent(0x5DF00000) != child(0x370000)
2 [main] ruby 3052 child_info_fork::abort: C:\cygwin\bin\cygpixman-1-0.dll: Loaded to different address: parent(0x5DF00000) != child(0x2B50000)

Supposedly, this problem should all but disappear in a 64-bit version of Cygwin, but I had problems with that too. Namely, curl is faulty, and this is critical to some of the other installation processes on which I rely. So, I had to stick with the 32-bit version of Cygwin and figure out how to continue without RMagick.

My Solution

Though the rebase issue is more general than just Ruby and ImageMagick, it was only since I started loading RMagick in my project that I started having fork() problems. So, I had considered replacing RMagick with the (more lean) FreeImage Ruby bindings (i.e. the free-image gem), and even got it working in a way that I liked… But I then learned that it has no support for vector images (e.g. SVG files), and I rely on this for many diagrams in my site. So, what to do?

I decided to rework the RMagick code I had and instead call the convert command-line utility provided with a standard installation of ImageMagick. This is a bit of a kludge, but I simply couldn’t find a way to get RMagick to work properly in my app under Cygwin. I left the RMagick code in place for other platforms, but routed around it to instead call system("convert ...") when using Cygwin.

By way of an example, the following RMagick code:

# Load the image:
pic ="my_file.png").first
# Resize down (hence trailing ">" after dimensions) to fit a 400x300 space:
pic.change_geometry("400x300>") do |cols, rows, img|
  img.resize!(cols, rows, Magick::CatromFilter)
# Reduce to 64 colours without dithering:
pic = pic.quantize(64, Magick::YUVColorspace, Magick::NoDitherMethod)
# Write out an 8-bit PNG image:

…became something like this:

# Build one long command-line string...
# Load the file:
cmd =  "convert my_file.png "
# Resize (scale down, only; not up-size) to fit within a 400x300 space:
cmd << "-resize '400x300>' "
# Reduce to 64 colours (web optimisation):
cmd << "-quantize yuv +dither -colors 64 "
# Write out the file as an 8-bit PNG:
cmd << "png8:output_file.png"
# Now call the command...
convert_ok = system(cmd)
raise "ERROR: convert command failed with status: $?" unless convert_ok

The Steps

This documents what I did to install Cygwin from scratch, with some additions, followed by RVM, Ruby, and ImageMagick.

Part 1: Install Cygwin

I had to install the 32-bit version of Cygwin because it looks like there is a bug with the 64-bit version of curl on Cygwin. This leads to problems including:

  • Cannot install RVM easily.
  • apt-cyg is broken.

So, this is the procedure I followed, influenced by instructions for Installing RVM on Cygwin:

  1. Download the Cygwin Installer, specifically the 32-bit version: setup-x86.exe.

  2. Make sure you are an Administrator when you run the installer, and if you’re using Windows Vista, 7, or above, be sure to right-click the installer and select the “Run as Administrator” option.

  3. Advance through the wizard to the “Local Package Directory” and specify C:\cygwin_setup.

  4. Advance through to the mirror list and choose any mirror which sounds close to you. In principle, any mirror should do, though occasionally some of them are not completely up-to-date.

  5. In the package list, add the following besides the defaults:

    colorgcc      (if available)
    gcc           (note that this is "Src?" only)
    gcc-core      (this is the compiler)
    mercurial     (if available)
  6. Proceed with the installation and it starts downloading what it needs.

  7. At the end, launch the “Cygwin Terminal” as Administrator and verify it seems to work OK, optionally setting the scrollback count to 20,000 lines or more.

Part 2: Install devtools and RVM

The devtools repository is an unofficial set of scripts to assist with setting up an RVM environment, including a script for Cygwin. These instructions are taken from: Installing RVM on Cygwin.

  1. Run the following commands (noting that the actual paths are important, in this case):

    mkdir -p repositories/developwithpassion
    cd repositories/developwithpassion
    git clone git://
    cd devtools
  2. This will have created a file such as $USER.settings (i.e. your_windows_user.settings) which you can alter to:

    1. Specify your GitHub account details (if you have one).
    2. Comment out all of the :windows[:paths] options, since they probably are not relevant for your machine (as they were indeed not relevant for mine).
  3. Run this command again:


    …which will now use your ...settings file to do its install.

  4. You may see some errors along the way, but just ignore them until you see a prompt to press any key to continue; hit ENTER each time it prompts you.

  5. As it progresses, it will compile a version of Ruby (1.9.3?) and this will take a while; probably more than 15 minutes. Afterwards it will wait for you to hit ENTER again before trying to install Ruby 2.0.0.

  6. NOTE: It may stall while installing Ruby 2.0.0, after this point:

    Installing rubygems-2.0.6 for ruby-2.0.0-p247.........(and so on)......
    Installation of rubygems completed successfully.
    Saving wrappers to '/home/anton/.rvm/wrappers/ruby-2.0.0-p247'...........
    ruby-2.0.0-p247 - #adjusting #shebangs for (gem irb erb ri rdoc testrb rake).
    ruby-2.0.0-p247 - #importing default gemsets, this may take time.................

    After waiting at least half an hour, I hit CTRL+C. It gave some errors, but I was able to proceed as follows…

  7. Exit the Cygwin Terminal and launch it again. This will ensure the correct environment gets loaded.

  8. At this point, you will probably be on Ruby 2.0.0. Install the latest Ruby 1.9.3 and switch to it:

    rvm install 1.9.3
    rvm use 1.9.3 --default

Part 3: Install apt-cyg

apt-cyg is loosely equivalent to APT (e.g. apt-get). It is a way to search for, and install packages from the Cygwin command-line. It is not perfect but can be a convenient way to install packages on demand or via a script. I recommend installing it, as it may come in handy.

  1. Run the following commands, which dump apt-cyg directly into your path and then make it executable:

    svn --force export /bin/
    chmod +x /bin/apt-cyg
  2. Use apt-cyg to install something:

    apt-cyg install bc
  3. Verify that it worked:

    bc --version

NOTE: If you retrospectively install any packages with apt-cyg (or the Cygwin setup-x86.exe for that matter), you may need to take the following steps, if you start getting errors related to fork():

  1. Exit out of any Cygwin processes, including the Cygwin Terminal.

  2. Launch a Windows Command Prompt, “As Administrator”.

  3. Run:

    c:\cygwin\bin\dash -c '/usr/bin/rebaseall'

Part 4: Enable OpenSSH server

This assumes you want to be able to SSH into your machine and use the Cygwin command-line (i.e. your default shell in Cygwin). Being able to do so is quite convenient, but not required in this process, and may pose security risks depending on your circumstances.

The steps below are based on these instructions:

  1. Run:

    ssh-host-config -y

    …and when prompted, supply any password for the cyg_server user that it will create.

  2. Log in as each user that will need SSH access (or just stay as the current user), and per each run:

    ssh-user-config -y

    …hitting ENTER to avoid entering a passphrase for each key.

  3. Start the sshd service with:

    cygrunsrv -S sshd
  4. You should now be able to SSH into your host, with your Windows username and password.

NOTE: Doing this will probably reveal a new “Privileged server” user on your Windows login screen. For more info, see: here.

Part 5: Fix vim config

vim is my preferred editor. If you don’t use it, you can skip this section.

  1. Grab a template that fixes cursor keys:

    cp /usr/share/vim/vim73/vimrc_example.vim ~/.vimrc
  2. Add the following to it for other enhancements:

    " Add these if needed:
    "   filetype plugin indent on
    "   syntax on
    " Two-space soft tabs, always:
    set tabstop=2
    set softtabstop=2
    set shiftwidth=2
    set expandtab
    " Line numbers:
    set number
    " Disable backup files:
    set nobackup

Part 6: Set yourself up for GitHub

Again, these steps are only required if you plan to use git (and GitHub).

  1. Create a place where project repos can be kept. For example:

    cd ~
    mkdir /cygdrive/c/projects
    ln -s /cygdrive/c
    ln -s c/projects
  2. Configure Git:

    git config --global color.ui true
    git config --global "Your Full Name"
    git config --global ""
  3. Set up GitHub SSH keys.

Part 7: Create an example Ruby project

  1. Create a directory for your project:

    cd ~/projects
    mkdir mydemo
    cd mydemo
  2. Create files that tell RVM which Ruby version to use, and that you want a specific set of gems to be tracked for this project:

    echo "1.9.3" > .ruby-version
    echo "mydemo-gemset" > .ruby-gemset
  3. Change out of, and back into the directory, to get it to reload the RVM config:

    pushd ~
    rvm list gemsets

    …the final line of which should show something like:

    => ruby-1.9.3-p448@mydemo-gemset [ i386 ]
  4. Install Bundler:

    gem install bundler
  5. Create a Gemfile which is used by Bundler, for now just to select v1.1.1 of the adsf gem:

    source ''
    gem 'adsf', '1.1.1'
  6. Test Bundler, getting it to read and respect Gemfile:

    bundle install
  7. Test that it worked:

    which adsf
    # /home/myuser/.rvm/gems/ruby-1.9.3-p448@mydemo-gemset/bin/adsf


If you get child_info_fork errors, try:

  1. Run this command, to find any modules (i.e. that may have been installed by Ruby gems):

    find ~ -iname '*.so' > /tmp/
  2. Exit any Cygwin Terminals or processes.
  3. Go in to an Administrator command prompt and run:

    c:\cygwin\bin\dash -c '/usr/bin/rebaseall -T /tmp/'
The cube, solved
